| Processor |
| Number | Up to Two 12-Core (One per CPU/Memory Unit) |
| Architecture | Type: SPARC64 12-Core Processor |
| CPUs M12-2S | SPARC 4.25GHz 12-Core (64KB data, 64KB per core L1, 512KB I$ per core L2, 32MB L3$ per CPU)
One CPU on the Upper CPU/Memory Unit (CMUU)
One CPU on the Lower CPU/Memory Unit (CMUL) |
| Main Memory |
| Capacities | Total DIMM slots: 16 per CPU socket (32 total DIMM slots x 2 CPU sockets)
DIMM type: DDR4 2400MHz Registered DIMMs
DIMM size: 8GB, 16GB, 32GB and 64GB
Maximum capacity: 2TB (when configured with 64GB DIMMs and 2 CPU sockets)
|
| Standard Integrated Interfaces |
| Network | Four 10GbE Ethernet Ports
|
| Service Processor | Two 1000 Base-T RJ45 network ports
One RJ45 serial management port
Two USB Maintenance ports |
| SAS | Two SAS-2 controllers providing hardware RAID 0, 1 and 1E/10 (ZFS file system provides higher level RAID) |
| USB | Front: One USB 2.0 port
Rear: One USB 3.0 port |
| PCI Expansion Slots | Eight low profile PCI Express 3.0 slots (8 x8 electrical/mechanical) |
| Internal Mass Storage |
| Disks | Up to eight front accessible disk bays with 2.5" SAS disks or eight solid-state drives (SSDs)
Drive Type
| Density
| Speed
| Form Factor
| SAS
| 600 GB
| 10,000 RPM
| 2.5"
| SAS
| 900 GB
| 10,000 RPM
| 2.5"
| SAS-2 Solid State Drive
| 400 GB
| NA
| 2.5"
| SAS-2 Solid State Drive
| 800 GB
| NA
| 2.5"
|
|
| XB-Box (Crossbar box) (XBUQB_A) |
| Number of Building Block Modules that can be connected | XB-Box x 2 (4Ux2) = up to 32 CPU's or sockets
Note: Used to connect BB Modules for system configurations larger than 16 CPU's or sockets (4BBs) |
| Service Processor | Redundant with XB-Box configuration.
XSCF in XB-Box becomes Master.
Two XB-Boxes provide redundancy (Master-Slave roles). |
| Power Supplies |
Four hot-swappable AC 1,800 W redundant (2 + 2) power supplies
Voltage 200 to 240 VAC, frequency 50Hz/60Hz
Maximum operating input current at 200 V AC: 17.2 A
Maximum operating input power at 200 V AC: 2,906 W |
| Environment |
| Temperature | Single, non-rack system:
Operating: 5° C to 35° C (41° F to 95° F) 0 to 500 m
Nonoperating: -25° C to 60° C (-13° F to 140° F)(packed)
Nonoperating: 0 to 50° C (32° F to 122° F)(unpacked) |
| Humidity | Single, non-rack system:
Operating: 20% to 80% relative humidity noncondensing
Nonoperating: 8% to 80% relative humidity noncondensing |
| Altitude | Single, non-rack system:
Operating: up to 3000 m (9,843 ft.), maximum ambient temperature is derated by 1° C per 300 m above 900 m
Nonoperating: up to 12,000 m (40,000 ft.) |
Regulations
Meets or exceeds the following requirements: |
| Safety | UL/CSA 60950-1, EN60950-1, IEC 60950-1 CB Scheme with all country differences |
| EMC | Emissions: FCC CFR 47 Part 15, ICES-003, EN 55032, KN32, VCCI V3/2015-04, EN61000-3-2, EN 61000-3-3, JIS C 61000-3-2 |
| Immunity | EN55024, KN35 |
| Certifications | North America Saftey (NRTL), European Union (EU), International CB Scheme,
BSMI (Taiwan), RCM (Australia), MSIP (Korea), VCCI (Japan), EAC (Eurasia)
|
| Dimensions and Weight |
| Height | 175 mm (6.89 in.); 4U |
| Width | 440 mm (17.32in.) |
| Depth | 800 mm (31.5 in.) |
| Weight | 60 kg (127.87 lb.) |
| Rack Mounting |
| Fujitsu M12-2 Server Rack | Rack is as follows:- Fujitsu Expansion Rack
- Sun Rack II 1042
- Sun Rack II 1242
- Sun Rack 900-38
- Sun Rack 1000-38
- Sun Rack 1000-42
- Sun Rack 900-36N
|
