| Processor |
| Number | One 6-Core (48 threads) |
| Architecture | Type: SPARC64 XII 6-Core Processor |
| CPUs M12-1 | SPARC 3.2GHz 6-Core (16MB L3 cache)
|
| Main Memory |
| Capacities | Total DIMM slots: 16
DIMM type: DDR4 2400MHz Registered DIMMs
DIMM size: 8GB, 16GB, 32Gb or 64GB
Maximum capacity: 1TB (when configured with 64GB DIMMs)
|
| Standard Integrated Interfaces |
| Network | Four 10GbE Ethernet Ports
|
| Service Processor | One dedicated TIA/EIA-232-F asynchronous RJ45 port
One USB Maintenance port
Two 1GbE Ethernet Ports |
| SAS | One 6Gbps channel SAS-2 interface |
| USB | Front: One USB 2.0 port
Rear: One USB 3.0 port |
| PCI Expansion Slots | Three low profile PCI Express 3.0 slots (3 x8 electrical/mechanical) |
| Internal Mass Storage |
| Disks | Up to eight front accessible disk bays with 2.5" SAS disks or eight solid-state drives (SSDs)
Drive Type
| Density
| Speed
| Form Factor
| SAS
| 900 GB
| 10,000 RPM
| 2.5"
| SAS
| 600 GB
| 10,000 RPM
| 2.5"
| SAS Solid State Drive
| 400 GB
| NA
| 2.5"
| SAS Solid State Drive
| 800 GB
| NA
| 2.5"
|
|
| Power Supplies |
Dual redundant, hot swappable power supplies
Maximum AC input = Max 785W (at 100-120VAC), Max 774W (at 200-240VAC) |
| Environment |
| AC power | 100-120 / 200-240 VAC (1-phase) |
| Temperature | Single, non-rack system:
Operating: 5° C to 35° C (41° F to 95° F)
Nonoperating: -25° C to 60° C (-13° F to 140° F)(unpacked)
|
| Humidity | Single, non-rack system:
Operating: 20% to 80% relative humidity noncondensing
Nonoperating: 20% to 80% relative humidity noncondensing (unpacked) |
| Altitude | Single, non-rack system:
Operating: up to 3000 m (9,843 ft.), maximum ambient temperature is derated by 1° C per 300 m above 900 m
Nonoperating: up to 12,000 m (40,000 ft.) |
Regulations
Meets or exceeds the following requirements: |
| Safety | UL 60950-1 2nd Ed, EN60950-1:2006 2nd Ed, CB Scheme with all country differences |
| RFI/EMI | EN55032:2015Class A, EN 61000-3-2:2014, EN61000-3-3:2013, FCC Part-15 Supart B: 2017 Class A |
| Immunity | EN55024:2010, GOST CISPR 24-2013 |
| Dimensions and Weight |
| Height | 42.5 mm (1.67 in.) |
| Width | 431 mm (16.97 in.) |
| Depth | 721 mm (28.39 in.) |
| Weight | 18 kg (39.68 lb.) maximum assuming PCI-Express card weighs 0.12 kg
(0.25 lb) each, and without the rack mounting slide rail kit installed. |
| Rack Mounting |
| Fujitsu M12-1 Server Rack | Rack is as follows:- Fujitsu Expansion Rack
- Sun Rack II 1042
- Sun Rack II 1242
|
