| Processor |
|
|
| Number | Up to two (maximum)
Both processors communicate with each other and the system I/O through the 200MHZ Jbus interface, which operates at a bandwidth of 3.2Gbit per second. |
|
|
| Architecture | 1.6GHz UltraSPARC IIIi: |
|
|
| Cache memory | 1MB Level 2 |
|
|
| Main Memory |
|
|
| Capacities | Characteristics of the ECC-protected memory include:- Maximum system memory - 16GB (DDR-1)
- Maximum memory per CPU - 8GB (using 2GB DIMMS)
- Maximum DIMMS per CPU - 4 (8GB max per processor)
- Maximum DIMM slots - 8 (4 slots per CPU)
- Two physical banks of two DIMMs per CPU
- DIMM sizes offered - 512MB, 1GB, or 2GB
- DDR-1 registered ECC memory at 266 MHz
- Processor accesses memory across the 128-bit data bus. Must be installed in pairs.
|
|
|
| Standard Interfaces |
|
|
| Audio | Four AC97 ports as follows: |
|
|
| Ethernet | Two 10/100/1000 BaseT (Gigabit) ethernet ports (rear of workstation) |
|
|
| Expansion Slots | Five slots as follows:- Two PCI-Express: both mechanical (x16) and electrically (x8)
- One PCI-Express mechanical (x8) and electrically (x4)
- Two PCI-X 100MHz/64 bit slots
|
|
|
| Serial | Two ports (rear of workstation) |
|
|
| USB | Six ports as follows:- Two USB 2.0 ports in front
- Four USB 2.0 ports in rear
|
|
|
| Internal Storage |
|
|
| Disks | Allows a maximum of four internal 3.5" SAS (146GB - 15000 RPM) or SATA (250GB - 7200 RPM) disk drives. Drives are supported by an integrated PCI-X SAS/SATA disk controller. |
|
|
| Optical Disk Drives | Optical disk drive as follows:- One DVD-RW - Slot-loading
- ATAPI - Interface
Note: Systems that ship without an optical disk drive require an optical disk drive EMI filler panel in the unoccupied bay to cover the slot opening. |
|
|
| Graphics |
|
|
| Cards | Note: Solaris 10 currently does not support dual graphics cards, each driving a monitor. |
|
|
| Environment |
|
|
| AC Power | Voltage: 110-127/200-240 VAC
Frequency: 50-60 Hz, 10/6 Amps |
|
|
| Input Current | 6.4 amps @ 100 VAC, 3.2 amps @ 200 VAC
|
|
|
| Power consumption | Power Supply - 1000 Watts (maximum) |
|
|
| Temperature | Operating: 5° C to 35° C at 3000 meters
Nonoperating:-40° C to 60° C at 12000 meters |
|
|
| Humidity | Operating: 7% to 93% relative humidity, non-condensing
Nonoperating: 93% relative humidity, non-condensing |
|
|
| Acoustic noise | Operating:LWAd (1B=10db) 5.0 B
LpAm (by standard position) 42 dBA
Idling: LWAd (1B=10db) 4.5 B
LpAm (by standard position) 38 dBA
|
|
|
| Shock | Operating: 5 G's, 11 msec, half-sine
Nonoperating: 30 G's, 11 msec, half-sine |
|
|
| Regulations |
|
|
| Meets or exceeds the following requirements: |
| Safety | IEC60950, UL60950, EN60950, CSA C22.2 CB |
|
|
| RFI/EMC | FCC B, VCCI B, EN55022 B |
|
|
| Immunity | EN55024 All applicable levels |
|
|
| Regulatory Markings | FCC, VCCI, ICES-003, CCC, C-tick, GOST, MIC, Argentina S mark, EEE, BSMI |
|
|
| Ergonomics | EK1-1TB-2000 |
|
|
| Power Management | EPA MOU 3 |
|
|
| Dimensions and Weights |
|
|
| Height | 445 mm (17.5 in) |
|
|
| Width | 205 mm (8.1 in) |
|
|
| Depth | 569 mm (22.4 in) |
|
|
| Weight | 26.31 kg (58 lbs) fully configured
|
|
|
